Black Lion Audio Revolution 2x2 is a compact, 2‑in/2‑out USB audio interface designed to deliver “modded‑out‑of‑the‑box” performance, using premium components and advanced clocking. It brings the clarity and punch of high‑end studio gear into a portable, bus‑powered desktop unit that is ideal for project studios, mobile recording and serious home production.
Revolution 2x2 features two high‑quality mic/line/Hi‑Z preamps, a fully balanced analog signal path, Black Lion’s Macro‑MMC clocking and PG‑i power filtering technology. It offers 24‑bit / 192 kHz conversion, direct monitoring with mix control, coaxial S/PDIF I/O and a comprehensive software bundle (including Presonus Studio One Artist plus plug‑ins from iZotope, Brainworx and Lindell), giving you a complete recording solution straight out of the box.
KEY FEATURES
- High‑quality 2‑in/2‑out USB audio interface with “modded‑grade” sound
- Two mic/line/Hi‑Z preamps on XLR/TRS combo inputs
- Fully balanced analog signal path with premium Vishay, Nichicon and Wima components
- Macro‑MMC clock for highly accurate AD/DA conversion
- PG‑i internal power filtering to minimise noise from the USB bus
- 24‑bit / 192 kHz conversion with very low distortion and wide dynamic range
- Direct monitoring with mix control and mono switch for zero‑latency tracking
- Two balanced 1/4" TRS line outputs for studio monitors plus a dedicated 1/4" headphone output with its own level control
- Coaxial S/PDIF input and output for connecting external converters or digital gear
- Bus‑powered over USB – no external power supply required
- Rugged, compact desktop chassis suited for both studio and mobile workflows
- Included software bundle: Presonus Studio One Artist and selected plug‑ins and processing tools
TECHNICAL SPECIFICATIONS
- Type: 2‑in/2‑out USB audio interface
- Resolution: up to 24‑bit / 192 kHz
- Analog inputs: 2 × XLR/TRS combo (mic/line/Hi‑Z)
- Analog outputs: 2 × balanced 1/4" TRS line out, 1 × 1/4" stereo headphone out
- Digital I/O: 1 × S/PDIF in (coaxial), 1 × S/PDIF out (coaxial)
- Power: USB‑C bus‑powered
- Monitoring: direct monitoring with MIX control and MONO switch
- Phantom power: switchable +48 V for the mic preamps
- Computer connection: USB 2.0 over USB‑C, compatible with macOS and Windows
- Use cases: recording vocals and instruments, music production, podcasting, mobile studio work
