Antelope Audio Discrete 8 Pro Synergy Core is a high-end 26 x 32 rackmount audio interface, combining Thunderbolt 3 and USB 2.0 connectivity with onboard real-time processing powered by Antelope’s Synergy Core engine (DSP + FPGA). Designed for modern studios, it delivers pristine audio quality and flexible I/O options in a professional 1U format.
Equipped with eight discrete ultra-low-noise Class A microphone preamps with up to 65 dB of gain, the Discrete 8 Pro offers combo XLR/TRS inputs for microphones and line-level sources. The interface includes two powerful headphone outputs, balanced monitor outputs, eight line outputs, two Reamp outputs, and digital ADAT and S/PDIF I/O. Three Word Clock outputs and one Word Clock input ensure tight sync with other digital devices.
Discrete 8 Pro Synergy Core supports up to 90 real-time effects processed internally, features a comprehensive digital routing matrix, and ensures ultra-low latency conversion at resolutions up to 192 kHz / 24-bit. This interface is ideal for producers, engineers, and studios looking for pristine audio performance, powerful processing, and maximum workflow flexibility.
KEY FEATURES
- 26 x 32 rackmount audio interface
- Thunderbolt 3 and USB 2.0 dual connectivity
- Synergy Core engine: onboard DSP + FPGA with ultra-low latency
- 8 discrete ultra-low-noise Class A mic preamps (up to 65 dB gain)
- Combo XLR / 1/4" TRS inputs on all channels
- 2 high-power headphone outputs
- 2 balanced monitor outputs (TRS)
- 8 line outputs (TRS)
- 2 dedicated Reamp outputs (TS)
- Digital I/O: ADAT In/Out, S/PDIF In/Out
- Word Clock I/O: 3 x Out, 1 x In (BNC)
- Supports up to 90 real-time Synergy Core FX
- Advanced internal DSP mixer and routing matrix
TECHNICAL SPECIFICATIONS
- Total I/O: 26 inputs / 32 outputs
- Computer Connection: Thunderbolt 3, USB 2.0 (Type B)
- Mic Preamps: 8 x Class A discrete, combo XLR/TRS
- Instrument/Line Inputs: 2 x 1/4" TS (channels 1–2)
- Line Outputs: 8 x 1/4" TRS
- Monitor Outputs: 2 x 1/4" TRS
- Headphone Outputs: 2 x 1/4" TRS
- Reamp Outputs: 2 x 1/4" TS
- Digital I/O: 2 x ADAT In, 2 x ADAT Out, 1 x S/PDIF In, 1 x S/PDIF Out
- Word Clock: 3 x Out, 1 x In (BNC)
- Sample Rates: 44.1 / 48 / 88.2 / 96 / 176.4 / 192 kHz
- Bit Depth: 24-bit
- Power Supply: External 12V DC adapter
- Dimensions: 483 x 200 x 44 mm (1U rack)
- Weight: approx. 2.6 kg
